Model No: HOG10DN1024I-LR-16H7-KLK-AX
HOG10DN1024I-LR-16H7-KLK-AX
Blind Hollow Shaft HeavyDuty Incremental Encoder; Bore Dia. 16mm (16H7x53mm); Supply Voltage: 9 to 30 Vdc; Output Signals: HTL with Inverted Signals (6-Channels); 1024 ppr; Dust Protection; Connection: Terminal Cover - Axial; IP 66
Quantity :
BOUMER HOG10DN1024I-LR-16H7-KLK-AX - 11070362 Incremental Encoder
The incremental encoder is a type of encoder that generates incremental pulses as the output. It measures the relative position or movement by counting the pulses. Each pulse represents a certain increment or displacement.
An incremental encoder typically consists of a rotating disk with evenly spaced slots or lines. As the encoder rotates, a sensor detects the changes in the slots or lines and generates electrical signals, usually in the form of pulses.
The incremental encoder provides information on the relative position or movement, rather than the absolute position. It measures the change in position by counting the pulses generated. By tracking the number of pulses, the encoder can determine the distance traveled or the rotational position.
The incremental encoder is commonly used in various applications, such as robotics, CNC machines, motor control, and industrial automation. Its simple design, high resolution, and cost-effectiveness make it a popular choice for many applications that require position or movement sensing.
Products Description
- Place of Origin: Germany
- Brand Name: BOUMER
- Model Number: HOG10DN1024I-LR-16H7-KLK-AX
- Product name: HOG10DN1024I-LR-16H7-KLK-AX
- Description: Blind Hollow Shaft HeavyDuty Incremental Encoder; Bore Dia. 16mm (16H7x53mm); Supply Voltage: 9 to 30 Vdc; Output Signals: HTL with Inverted Signals (6-Channels); 1024 ppr; Dust Protection; Connection: Terminal Cover - Axial; IP 66
- Stock: Available
- Quality: 100% Brand
- Condition: 100%Original and new
- Delivery time: 1- 50pcs ，3-7 days51-100 pcs，7-10days
- Datasheet: Download
