Model No: VAL-MS-T1/T2 335/12.5/3+0-FM

VAL-MS-T1/T2 335/12.5/3+0-FM - Lightning/surge arrester type 1/2 - 2800188

Universal varistor-based plug-in lightning/surge arrester for 3-phase power supply networks with common N and PE (4-conductor system: L1, L2, L3, PEN), with remote indication contact.

minimum order :

1 piece

Quantity :

Contact Now

VAL-MS-T1/T2 335/12.5/3+0-FM - Lightning/surge arrester type 1/2 - 2800188

Lightning and surge arresters are devices that protect electrical equipment from the damaging effects of lightning strikes and power surges. These events can cause serious damage to electrical equipment such as computers, televisions, and other sensitive electronics, and can even cause injury or death to people who are in contact with the equipment.

Lightning and surge arresters work by diverting the excess voltage and current to ground, rather than allowing it to enter the electrical equipment. They are installed in the electrical system at the point where the power enters the building or device, and are designed to withstand high-voltage surges that may occur from lightning strikes or other sources.

There are several types of lightning and surge arresters available, including gas discharge tubes, metal oxide varistors, and silicon avalanche diodes. Each type has its own unique characteristics and is designed to protect different types of electrical equipment.

In addition to protecting electrical equipment, lightning and surge arresters also help to improve the overall reliability and safety of the electrical system. They help to prevent fires, reduce the risk of electrocution, and ensure that equipment is able to operate at its maximum performance level.

Overall, lightning and surge arresters are an essential part of any electrical system that is designed to protect equipment and prevent damage from lightning strikes and power surges. By investing in high-quality lightning and surge arresters, we can ensure that our electrical systems are safe, reliable, and able to withstand even the most severe weather conditions.

Place of Origin:Germany
Brand Name:Phoenix Contact
Model Number:VAL-MS-T1/T2 335/12.5/3+0-FM
Number of Pole:4
Rated Voltage:5 V AC ... 250 V AC
Product name:Phoenix Contact Class 1/2 Lightning/Surge Protector
Order NO: 2800188
Stock: Available
Quality: 100% Brand
Condition: 100%Original and new
Delivery time: 1- 50pcs ，3-7 days，51-100 pcs，7-10days
