Model No: CB TM1 5A F1 P

2800862 CB TM1 5A F1 P Phoenix Contact Thermal Magnetic Device Circuit Breakers

Thermomagnetic device circuit breaker, 1-pos., tripping characteristic F1 (fast-blow), 1 changeover contact, plug for base element.

minimum order :

1 piece

Quantity :

Contact Now

CB TM1 5A F1 P - Thermomagnetic device circuit breaker - 2800862

Thermomagnetic device circuit breakers are essential components in the electrical industry. They are responsible for controlling and protecting electrical systems from dangerous overloads and short circuits. The device is made up of two parts, the thermal trip and the magnetic trip.

The thermal trip uses an electrical resistance element to measure the temperature of the circuit breaker. When the temperature exceeds a certain level due to an overload or short circuit, the thermal trip quickly opens the breaker and stops the flow of electricity. This helps to prevent damage to the electrical system from overloading.

The magnetic trip, on the other hand, works by using a coil wound around an iron core to generate a magnetic field. When the current in the circuit exceeds a certain level due to a short circuit or ground fault, the magnetic trip quickly opens the breaker to stop the flow of electricity.

Thermomagnetic device circuit breakers have many advantages over traditional fuses. They are more reliable and more accurate at detecting overloads and short circuits. They are also easier to reset after a trip and can handle multiple trips without degrading their performance.

In addition, thermomagnetic device circuit breakers are environmentally friendly and more energy efficient than fuses. They do not require replacement after every trip, as fuses do, which reduces waste and conserves resources.

Overall, thermomagnetic device circuit breakers are an essential and important component in the electrical industry. They provide efficient and reliable protection to electrical systems, ensuring safety and reducing the risk of damage or fire.

Place of Origin:Indonesia
Brand Name:Phoenix Contact
Model Number:CB TM1 5A F1 P
Poles Number:5
Rated Voltage:50 V DC
Product name:Thermal Magnetic Device Circuit Breakers
Order NO: 2800862
Stock: Available
Quality: 100% Brand
Condition: 100%Original and new
Delivery time: 1- 50pcs ，3-7 days，51-100 pcs，7-10days
